PEG2BI5SC6 GB Ethernet Card
Security Accelerator and Dual Port Copper Multifunction PCI-Express Bypass Server Adapter Cavium® Based
This product has been discontinued – EOL Notification
Silicom’s Security Accelerator and Dual Port Copper Multifunction Bypass Server adapter is integrative PCI Express X8 adapter that include Security Process accelerator and Bypass Gigabit Ethernet ports on a PCI Express adapter.
Silicom’s Security Accelerator and Dual Port Copper Multifunction Bypass Server adapter is based on Cavium NITROX CN1620 security processor accelerator and Intel 82575 Gigabit Ethernet controller.
Silicom’s Security Accelerator and Dual Port Copper Multifunction Bypass Server adapter is complete PCI Express server adapter solution that incorporates Gigabit Ethernet ports and security processor accelerator for IPSec, IKE, SSL and TLS protocol processing.
Silicom’s Security Accelerator and Dual Port Copper Multifunction Bypass Server adapter is the ideal solution for implementing multiple network segments, mission-critical high-powered networking applications and environments within high performance servers, and targeted to security servers / security appliances.
Silicom’s Security Accelerator and Dual Port Copper Multifunction Bypass Server adapter provides bulk cryptographic acceleration for 3DES, DES, AES and ARCFOUR symmetric encryption algorithms, for the SHA-1 and MD5 hash algorithm, and for the HMAC-SHA-1 and HMAC-MD5 keyed authentication algorithms.
It provides public key acceleration for the RSA, DSA, and diffie-Helman asymmetric algorithms, as well as basic Modular Math functions. Silicom’s Security Accelerator and Dual Port Copper Multifunction Bypass Server adapter provides a True Random Number Genrator and can use it to generate on-chip random values for Diffie-Helman key generation and DSA signatures.
Silicom’s Security Accelerator and Dual Port Copper Multifunction Bypass Server adapter provides combined encryption and HMAC authentication for single authentication for single-pass Ipsec processing. It also executes protocol-specific instruction to support the SSL/TLS or IPsec/IKE security protocols. Macro processing within the CN1620 processor, allows systems to offload high-level SSL or IPsec protocol commands that reduce the host I/O traffic and system processor to increase the total system throughput.
This also frees system processor resources for other functions, increasing overall system performance. Silicom’s Security Accelerator and Dual Port Copper Multifunction Bypass Server Adapter support Normal, Bypass and Disconnect modes.
In Normal mode, the ports are independent interfaces. In Bypass mode, all packets received from one port are transmitted to adjacent port. In Disconnect mode, the adapter simulates switch / rout cable disconnection. In Bypass mode, the connections of the Ethernet network ports are disconnected from the interfaces and switched over to the other port to create a crossed connection loop-back between the Ethernet ports.
Hence, in bypass mode all packets received from one port are transmitted to other port and vice versa. This feature enables to bypass a failed system and provides maximum up time for the network. In Disconnect mode, the adapter simulates switch / router cable disconnection. In Disconnect mode, the switch / router does not detect link partner of the adapter.
Silicom’s Gigabit Ethernet Bypass server adapters include an on board WDT (Watch Dog Timer) controller.
The adapter’s software drivers or software application can write commands to the on board WDT controller. The adapter’s software drivers, WDT controller and the Bypass circuitry provide an interface that control and manage the mode of the adapter.
PEG2BI5SC6 GB Ethernet Card
Security Accelerator and Dual Port Copper Multifunction PCI-Express Bypass Server Adapter Cavium® Based
Bypass:
- Bypass/Disconnect Ethernet ports on Power Fail, System Hangs or Software Application Hangs
- Software programmable Bypass, Disconnect or Normal Mode
- On Board Watch Dog Timer (WDT) Controller
- Software programmable time out interval
- Software Programmable WDT Enable / Disable counter
- Software programmable Bypass Capability Enable / Disable
- Software Programmable Disconnect Capability Enable / Disable
- Software Programmable mode (Bypass, Normal or Disconnect mode) at Power up
- Software Programmable mode (Bypass, Normal mode) at Power off
- Independent Bypass operation in every two ports
- Emulates standard NIC
Copper Gigabit Ethernet 1000Base-T :
- Independently copper Gigabit Ethernet channels support two and one Gigabit Ethernet (1000Base-T), Fast Ethernet (100Base-Tx) and Ethernet (10Base-T)
- Triple speed 1000Mbps (1000Base-T), 100 Mbps (100Base-Tx) and 10 Mbps (100Base-T) operation
- Nway auto negotiation automatic sensing and switching between 1Gbps full duplex and 100 / 10 Mbps operations Simplex or Full Duplex
- RJ-45 female connectors
Common Key features:
- Host Interface standard support PCI Express 1.1
- High performance, reliability, and low power use in Intel 82575 dual integrated MAC + PHY and SERDES chip controller
- Ultra deep packet buffer per channel lowers CPU utilization
- Hardware acceleration that can offload tasks from the host processor. The controllers can offload TCP/UDP/IP checksum calculations and TCP segmentation
- Priority queuing – 802.1p layer 2 priority encoding
- Virtual LANs –802.1q VLAN tagging
- Jumbo Frame (16KB)
- 802.x flow control
- Statistics for SNMP
- LEDs indicators for link/Activity/Bypass Disconnect Mode status
PEG2BI5SC6 GB Ethernet Card
Security Accelerator and Dual Port Copper Multifunction PCI-Express Bypass Server Adapter Cavium® Based
Bypass Specification: | |
WDT Interval (Software Programmable): | 3,276,800 mSec (3,276.8 Sec): Maximum 100 mSec ( 0.1 Sec) : Minimum WDT Interval = (2^wdt_interval_parameter)*(0.1) sec. wdt_interval_parameter: {Valid Range: 0-15} |
Copper Gigabit Ethernet Technical Specifications - (1000Base-T) Adapters: | |
IEEE Standard / Network topology: | Gigabit Ethernet, 1000Base-T Fast Ethernet, 100Base-TX Ethernet, 10Base-T |
Full duplex / Simplex: | Support both Simplex & Full duplex operation in all operating speeds |
Auto negotiation: | Auto-negotiation between Full duplex and simplex operations and between 10Mb/s 100Mb/s speeds and duplex 1000Mb/s |
Data Transfer Rate: | 1000 Mbit/s, 100 Mbit/s and 10 Mbits/sec in simplex mode per port 2000Mbit/s 200 and 20 Mbit/s in full duplex mode per port |
Cables and Operating distance: | Normal Mode (Bypass Off) Typical: -18.9 dBm Maximum: -18.6 dBm |
Insertion Loss: | 10Base-T Category 3, 4, or 5 maximum 50m * 100Base-Tx Category 5 maximum 50m * 1000Base-T Category 5E maximum 50m * *Theoretical Distance – Defined as half a distance as stated by the IEEE 802.3 standard |
Operating Systems Support | |
Operating system support: | Windows Linux FreeBSD VMware |
General Technical Specifications | |
Interface Standard: | PCI-Express Base Specification Revision 1.1 |
Board Size: | Low profile short add-in card: 167.64mm X 68.91mm (6.60”X 2.713”) |
PCI Express Card Type: | X8 |
PCI Express Voltage: | +3.3V ± 9%, +12V ± 8% |
PCI Connector: | Gold Finger: X8 |
Holder: | Metal Bracket: Full Height / low profile Height |
Weight: | 130 gram (4.589 Oz) |
Operating Humidity: | 0%–90%, non-condensing |
Operating Temperature: | 0°C – 50°C (32°F - 122°F) |
EMC Certifications: | FCC Part 15, Subpart B Class B Conducted Emissions Radiated Emissions CE EN 55022: 1998 Class B Amendments A1: 2000; A2: 2003 Conducted Emissions Radiated Emissions CE EN 55024: 1998 Amendments A1: 2000; A2: 2003 Immunity for ITE Amendment A1: 2001 CE EN 61000-3-2 2000, Class A Harmonic Current Emissions CE EN 61000 3-3 1995, Amendment A1: 2001 Voltage Fluctuations and Flicker CE IEC 6100-4-2: 1995 ESD Air Discharge 8kV. Contact Discharge 4kV. CE IEC 6100-4-3:1995 Radiated Immunity (80-1000Mhz), 3V/m 80% A.M. by 1kHz CE IEC 6100-4-4:1995 EFT/B: Immunity to electrical fast transients 1kV Power Leads, 0.5Kv Signals Leads CE IEC 6100-4-5:1995 Immunity to conductive surges COM Mode; 2kV, Dif. Mode 1kV CE IEC 6100-4-6:1996 Conducted immunity (0.15-80 MHz) 3VRMS 80% A.M. By 1kHz CE IEC 6100-4-11:1994 Voltage Dips and Short Interruptions V reduc >95%, 30% >95% Duration 0.5per, 25per, 250per |
LEDs | |
LEDs: | (3) LEDs per port Link/Activity: Turns on any link speed, blinks on activity (green). 100: Turns on 100 Mbit/s link (green). 1000: Turn on 1000 Mbit/s link (green). Bypass: LED 1000 (Port 0) and LED 100 (Port 0) are turn on. Disconnect: LED 1000 (Port 1) and LED 100 (Port 1) are turn on |
LEDs location: | LEDs are located on the PCB, visible via holes in the metal bracket holder |
Connectors: | (2) Shielded RJ-45 |
PEG2BI5SC6 GB Ethernet Card
Security Accelerator and Dual Port Copper Multifunction PCI-Express Bypass Server Adapter Cavium® Based
P/N | Description | Notes |
PEG2BI5SC6 - RoHS | Security Accelerator and Dual Port Copper Multifunction PCI-Express Bypass Server Adapter | RoHS Compliant, Based on 82575, CN1620 Low-Profile |
Note: Model P/N -SD/-LP /-RoHS
-SD: Side Driver
-RoHS: RoHS Compliant / Lead free adapter
-LP: Assemble low-profile metal bracket
