PE2G1FI35 Server Adapter

Single Port Fiber Gigabit Ethernet PCI Express Server Adapter Intel® i350AM2 Based

Silicom’s Single Port Fiber Gigabit Ethernet PCI Express Server adapter is PCI-Express X4 Fiber Gigabit Ethernet network interface card that is based on a single chip, non-Bridged Dual port GBE controller.

Silicom’s Single Port Fiber Gigabit Ethernet PCI Express Server adapter is the ideal solution for implementing multiple network segments, mission-critical high-powered networking applications and environments within high performance servers.



Silicom’s Single Port Fiber Gigabit Ethernet Server adapter is based on Intel i350 Gigabit Ethernet MAC+PHY of Intel Controller. The Silicom i350 support PCI-SIG Single-Root I/O virtualization and sharing specification (SR-IOV).

PE2G1FI35 Server Adapter

Single Port Fiber Gigabit Ethernet PCI Express Server Adapter Intel® i350AM2 Based

Performance Features:

• 8 Transmit and 8 Receive queues per port.
• Up to 8 queues of Receive Side Scaling (RSS) minimize CPU utilization across multiple processor systems.
• Support PCI-SIG Single-Root I/O virtualization Rev 1.1.

  • Support for up to 8 virtual function ( VFs)
  • Partial replication of PCI Configuration space
• Support for 8 pools (single queue) of virtual machine Device Queues (VMDq) per port.
• Support Direct Cache Access (DCA)
• Support Intel I/O Acceleration Technology v3.0.
• TSO interleaving for reduced latency
• Minimized device I/O interrupts using MSI and MSI-X
• UDP, TCP and IP checksum offload
• UDP and TCP transmit segmentation offload (TSO). machine
• SCTP receive and transmit checksum offload
• Packet interrupt coalescing timers (packet timers) and absolute-delay interrupt timers for both transmit and receive operation
• EEE (IEEE 802.3az) for reduced power consumption during low link utilization periods

Fiber Gigabit Ethernet 1000Base-SX:

• Independently Fiber Gigabit Ethernet channel/s support Gigabit Ethernet 1000Base-SX
• Small Form Factor (SFF) LC Connectors

Fiber Gigabit Ethernet 1000Base-LX:

• Independently Fiber Gigabit Ethernet channel/s support Gigabit Ethernet 1000Base-LX
• Small Form Factor (SFF) LC Connectors

Common Key features:

• Support PCI Express Base Specification 2.1 (5 GTs)
• High performance, reliability, and low power use in Intel i350 Dual integrated MAC + PHY and SERDES chip Controllers
• Ultra deep, packet buffer per channel lowers CPU utilization
• Hardware acceleration that can offload tasks from the host processor. The Controllers can offload TCP/UDP/IP checksum calculations and TCP segmentation
• Server class reliability, availability and performance features:

  • Link Aggregation and Load Balancing
• Priority queuing – 802.1p layer 2 priority encoding
• Virtual LANs –802.1q VLAN tagging
• Jumbo Frame (9.5KB).
• 802.x flow control
• Multicast/ broadcast Packet replication
• Supports Vital Product Data (VPD)
• LED indicator for link/Activity/Speed status

PE2G1FI35 Server Adapter

Single Port Fiber Gigabit Ethernet PCI Express Server Adapter Intel® i350AM2 Based

PE2G1FI35 Server Adapter

Single Port Fiber Gigabit Ethernet PCI Express Server Adapter Intel® i350AM2 Based

Note: Model P/N /S/-LP /

-LP: Assemble Low Profile Metal Bracket
