M1E2SSD Express Module

SETAC PCI Express SSD Module

Silicom Solid State Drive SETAC ExpressModule Server card is PCI-Express X8 Solid State Drive card that can fit into a 3.5” HD form factor. The Silicom Solid State Drive SETAC ExpressModule adapter is the front I/O module in Silicom Server to Appliance Converter (SETAC) architecture.

The Silicom Solid State Drive SETAC ExpressModule Server cards are based on LSI SAS2008 SAS/SATA I/O controller with eight 6GBPs SAS/SATA ports. The advanced Integrated RAID options include support for the Integrated Mirroring (RAID 1), Integrated Mirroring Enhanced (RAID 1E), Integrated Striping (RAID 0), and Integrated Striping/Integrated Mirroring (RAID 10) solutions.

Silicom’s Solid State Drive SETAC ExpressModule Server cards are the ideal solution for implementing storage with RAID0/1/1E/10 capabilities and high speed read/write within high performance servers.

M1E2SSD Express Module

SETAC PCI Express SSD Module

RAID Features The LSISAS2008 controller offers the following Integrated RAID features:

Integrated Mirroring (RAID 1)
Integrated Mirroring Enhanced (RAID 1E)
Integrated Striping (RAID 0)
Integrated Striping/Integrated Mirroring (RAID 10)

PCI Express Features The LSISAS2008 controller supports the following PCI Express 2.0 features:

PCI Power Management 1.2
Active State Power Management, including the L1 and L0s states, is supported by placing links in a power-saving mode when there is no link activity
32-deep command queue
Software compatibility with PCI and PCI-X software, which leverages existing PCI
PCI Express Traffic Class 0 and one virtual channel, with native support for 16 virtual functions (single-root)
Message Signaled Interrupts (both MSI and MSI-X), as well as INTx interrupt signaling for legacy PCI support

SAS Features: The LSISAS2008 controller supports the following SAS 2.0 features:

6Gb/s, 3Gb/s, and 1.5Gb/s SAS data transfers
Serial, point-to-point, enterprise-level storage interface
Wide data transfers using from two to eight phys
Narrow ports consisting of a single phy
Data transfers using SCSI information units
Compatibility with SATA target devices
T10 Data Protection information model
2 MB of on-chip EDRAM for context RAM
Greater than 2-TB addressing by means of 16-byte SCSI Read/Write/Verify CDB for SAS and SATA

SATA/STP: Features The LSISAS2008 controller supports the following SATA/STP features:

6Gb/s, 3Gb/s, and 1.5Gb/s SATA data transfers
6Gb/s, 3Gb/s, and 1.5Gb/s STP data transfers
Addressing of multiple SATA targets through an expander
Ability for multiple initiators to address a single target (in a failover configuration) through an expander

Common Key features:

PCI Express ExpressModule Electromechanical Specification Revision 1.0
Support PCI Express Base Specification 2.0 (2.5 GHz)

M1E2SSD Express Module

SETAC PCI Express SSD Module

Solid State Drive SETAC ExpressModule Server card Technical Specifications:
Solid State Drive SETAC ExpressModule Server card supports:	Eight PCI Express phys, with support for x8, x4, x2, and x1 link widths
Operating Systems Support
Operating system support:	Windows Linux VMware
General Technical Specifications
Interface Standard:	PCI Express ExpressModule Electromechanical Spec. Revision 1.0 Silicom SETAC PCI-Express Base Specification Revision 2.0 ( 5 GT/s)
Board Size:	168.2mm x 98mm (6.62”X3.858”)
PCI Express Card Type:	X8 Lane
PCI Express Voltage:	+12V +- 8%
PCI Connector:	Gold Finger: X8
Controller:	LSI LSISAS2008
Holder:	Not included
Weight:	0.190Kg (With 8 modules)
Power Consumption (with data):	19.8W
Power Consumption:	12.2W
Operating Temperature:	-5°C – 40°C (23°F - 105°F)
Storage:	-40°C–65°C (-40°F–149°F)
EMC Certifications:	FCC Part 15, Subpart B Class A Conducted Emissions Radiated Emissions CE EN 55022: 1998 Class A Amendments A1: 2000; A2: 2003 Conducted Emissions Radiated Emissions CE EN 55024: 1998 Amendements A1: 2000; A2: 2003 Immunity for ITE Amendment A1: 2001 CE EN 61000-3-2 2000, Class A Harmonic Curent Emissions CE EN 61000 3-3 1995, Amendement A1: 2001 Voltage Fluctuations and Flicker CE IEC 6100-4-2: 1995 ESD Air Discharge 8kV. Contact Discharge 4kV. CE IEC 6100-4-3:1995 Radiated Immunity (80-1000Mhz), 3V/m 80% A.M. by 1kHz CE IEC 6100-4-4:1995 EFT/B: Immunity to electrical fast transients 1kV Power Leads, 0.5Kv Signals Leads CE IEC 6100-4-5:1995 Immunity to conductive surges COM Mode; 2kV, Dif. Mode 1kV CE IEC 6100-4-6:1996 Conducted immunity (0.15-80 MHz) 3VRMS 80% A.M. By 1kHz CE IEC 6100-4-11:1994 Voltage Dips and Short Interruptions V reduce >95%, 30% >95% Duration 0.5per, 25per, 250per
MTBF(Without mSATA Modules):	186 Years
MTBF(With mSATA Modules):	24 Years
LEDs
LEDs location:	Active Led(Green), Error Led(Yellow)
Connectors:	LED is located on the PCB, visible via holes in the metal bracket holder on the right side

M1E2SSD Express Module

SETAC PCI Express SSD Module

P/N	Description	Notes
M1E2SSD-R	Solid State Drive SETAC ExpressModule Server card	x8 Gen2, ExpressModule, Based on LSI LSISAS2008
M1E2SSD-1T-C-R	Solid State Drive SETAC ExpressModule Server card with 1 TB Flash Storage	x8 Gen2, ExpressModule, Based on LSI LSISAS2008
