MicroFirewall (uFW)

IoT Security Appliance

  • Tiny 74 x 43 mm security appliance for IoT, Industrial, and BMC security
  • Enterprise grade security from pfSense
  • FreeBSD and Yocto Linux
  • Mount anywhere, Limitless use cases
  • TI ARM Cortex-A8 AM3352 CPU at 600 MHz
  • 4GB eMMC, 512MB DDR3
  • 2x Gb Ethernet ports, 2x USB 2.0 host
  • Expansion connector: GPIO, I2C, UART, Analog In
  • Board or complete system with case
  • Launching Q3 2016
silicom connectivity solutions microfirewall
silicom microfirewall

MicroFirewall (uFW)

IoT Security Appliance

General Technical Specifications

Form Factor74 x 43mm
CPUTI AM3352 ARM Cortex-A8 600 MHz, including crypto accelerator
DRAM512MB DDR3, memory down
EthernetTwo external 1GbE RJ45 ports
StorageeMMC on-board, 4GB (custom build options support up to 64GB)
MicroSD hinged socket
USB1x USB 2.0 host (Micro AB)
1x USB 2.0 host (header)
ConsoleUART over MicroUSB A
Expansion HeaderUART, I2C, GPIO, Analog In
RTCYes
Power5VDC coaxial power input connector
5VDC power input header
TemperatureOperating: 0-50C
AvailabilityQ3 2016

MicroFirewall (uFW)

IoT Security Appliance

P/N

Description

80500-0140-G00– TI AM3352 ARM Cortex-A8 600 MHz, including crypto accelerator
– 512MB DDR3
– 2x Intel Gb Ethernet RJ45
– 4GB eMMC
– Micro-USB console
– 1x USB 2.0 host



MicroFirewall (uFW)

IoT Security Appliance



arrow

MicroFirewall Prototype Manual
