Intel Atom® C3000 Processor series Based CPE Network Appliance



Silicom’s Nano CPE Network Appliance Based on Intel Atom® C3000 Processor series family is a low-cost edge device for OEMs taking SD-WAN, NFV-enabled CPE, security, small cell, or other edge products to market.

CPE Network Appliance Atom C3000

Intel Atom® C3000 Processor series Based CPE

Intel Atom® C3000 Processor series Based CPE Network Appliance

  • SoC. 2-4 core (fanless), 8-16 core (with fan cooling)
  • Nano-ITX Form Factor (120x120mm)
  • 4x Intel 1Gb Ethernet, 2x M.2 Cards (1x Cellular or SSD, 1x Wi-Fi/BT), eMMC onboard SSD, 1x USB3, Console
  • Optional 2x SATA, TPM
  • 1GB, 2GB, 4GB, and 8GB DDR4 Options (ECC optional)
  • Board only and Desktop appliance

Intel Atom® C3000 Processor series Based CPE

Intel Atom® C3000 Processor series Based CPE Network Appliance

General Technical Specifications

CPU – 2 to 16 cores, Frequencies from 1.5 Ghz to 2.2 Ghz
Ethernet – Up to 4x 1 GbE ports (RJ-45)
– M.2 Wi-Fi/BT radio card slot
WWAN – M.2 cellular radio card slot
Storage – eMMC onboard SSD options for 4, 8, 16, 32, 64 GB densities
– WWAN M.2 slot supports SATA 3.0 SSD cards
– Optional 2x offboard SATA 3.0 ports
I/O Connectors – 1x USB 3.0 port
– 1x micro-USB console port
Certifications

Emissions and immunity
         European standards EN55022, EN 61000-3-3, EN 610000-3-2, EN55024
         CISPR 22
         FCC Part 15 subpart B

Safety
         IEC 60950

CE Mark (covered by above certifications)
RoHS-6 (Pb-free) and REACH compliant

Intel Atom® C3000 Processor series Based CPE

Intel Atom® C3000 Processor series Based CPE Network Appliance

P/N

Description

80500-0138-G02 – C3338 CPU (1.50 GHz) 2-core, 4 MB cache
– Memory: 4 GB DDR4-1866
– 4x 1 GbE
– 32 GB eMMC SSD
– Fanless operation 0 to +40 C
Other SKUs Custom options available upon request
