Cordoba Edge Gateway CPE

Compact Intel® Atom® C3000-Based Universal CPE for SD-WAN and SD-Branch Applications

Silicom’s Cordoba series based on the Intel® Atom® C3000 processor replaces traditional purpose-built CPE hardware with a wide array of wired and wireless WAN options for maximum site installation flexibility while still maintaining a small desktop footprint and optimum price point.

LAN connectivity includes dual-band 802.11ax Wi-Fi 6 with internal antennas, as well as 2.5 Gbps RJ-45 ports supporting external 802.11ax access points at full bandwidth.

WAN connectivity includes 1 Gbps auto media copper/fiber ports to align with site-specific needs, 10 Gbps ports supporting fiber Ethernet and xgsPON installations, single or dual 4G LTE uplinks, or 5G sub-6 uplink.

Silicom Cordoba Edge Gateway CPE

Multiple WAN and LAN options, combined with multicore Intel® CPU Virtualization Technology (Intel® VT), enable flexible and powerful SD-WAN and SD-Branch solutions. Optional Intel® QuickAssist Technology (Intel® QAT) acceleration offloads application software, making integrated security features practical while minimizing CPU footprint.

Use Cases:

Silicom Cordoba Edge Gateway CPE FWA





Cordoba Edge Gateway CPE

Compact Intel® Atom® C3000-Based Universal CPE for SD-WAN and SD-Branch Applications

Feature

Description

CPU
  • 2, 4, and 8 core Intel® Atom® C3000, optional QAT
Memory
  • 1-channel, dual-rank DDR4 down, 2 to 32 GB total, optional ECC
Storage
  • Onboard eMMC SSD 8 GB to 256 GB
  • Optional NVMe SSD card*
WAN
  • Optional up to 2x 4G LTE radio cards, external antennas, dual SIM slots per card
  • Optional 5G sub-6 radio card, external antennas, dual SIM slots
  • 2x auto media detect 1 Gbps copper RJ-45/fiber SFP ports
  • 2x 10 Gbps ports for PON or SFP+ transceivers*
LAN
  • Optional 802.11ax Wi-Fi 6 AP, dual-band / dual-concurrent, internal antennas
  • 4x 2.5 Gbps RJ-45 ports
Local access
  • Cisco RJ-45 and micro-USB console port (auto-detect)
  • 2x USB-A 3.0 host ports
Security
  • TPM 2.0
  • Optional Secure Boot
  • Optional Hardware Root of Trust
Buttons
  • Protruding button, default CPU power button (programmable)
  • Recessed button, default CPU reset button (programmable)
LED
  • 3x front panel tricolor RGB LED’s, user configurable
Bootloader
  • Embedded Blinkboot UEFI
Power input
  • +12 VDC locking barrel jack, external desktop PSU, regional AC cord options
Environmental
  • 0 to +40C operating temperature
Mounting options
  • Default desktop feet; rackmount kit and wall-mount kit available
Dimensions
  • 256 x 200 x 44 mm W x D x H (10.1 x 7.9 x 1.7 in)
Environmental:
  • ESTI EN 300 019-2-1 V2.3.1 (2017-11)
  • ESTI EN 300 019-2-2 V2.4.1 (2017-11)
  • ESTI EN 300 019-2-3 V2.5.1 (2020-10)
  • IEC 60068-2-41:76 +A1:83
  • TIA-968-A:2002
  • ASTM D5276-19
  • ASTM D5445-21
Acoustic:
  • ETSI EN 300 753 V1.3.1
RoHS:
  • EN 50581: 2012
EMC:
  • FCC 47CFR part 15: 2021, subpart B, Class B ICES-003: 2020 Issue 7, Class B
  • ICES003
  • CISPR 32: 2015 + A1(19), Class B
  • CISPR 35: 2016
  • VCCI-CISPR 32: 2016, Class B
  • AS/NZS CISPR 32: 2015+A1(20), Class B
  • EN 55032: 2015 + A1(20) + A11(20), Class B
  • EN 55035: 2017 + A11(20)
  • EN 300 386: V2.1.1: 2016, equipment operating in locations other than telecommunication centers, Class B
  • EN 300 386: V1.6.1: 2012, equipment operating in locations other than telecommunication centers, Class B
  • EN 301 489-52: V1.2.1: 2021, Class B
  • EN 301 489-17: V1.2.1: 2020, Class B
  • EN 301 489-1: V2.2.3: 2019, Class B
  • EN 301 489-17: V3.2.4 (2020-09) Class B
  • EN 61000-3-3 : 2013 + A1(19)/A2:2021
  • EN 61000-3-2 : 2019 +A1(21)
  • BS EN55032
  • BS EN55035
Radio (Wi-Fi – AX210NGW):
  • EN 300 440 V2.2.1 (2018-07)
  • EN 301 893 V2.1.1 (2017-05)
  • EN 300 328 V2.2.2 (2019-07)
  • AS/NZS 4268:2017 + Amendment 1_2021
  • EN IEC 62311: 2020
  • BS EN IEC 62311: 2020
  • AS/NXS 2772.2 :2016_A1_2018
Safety:
  • IEC 62368-1:2014 (Second Edition)
  • IEC 60950-1:2005 (Second Edition) + A1:2009 + A2:2013
  • CSA C22.2 NO. 62368-1-14, 2nd Ed., Issue Date: 2014-12-01
  • UL 62368-1, 2nd Ed., Issue Date: 2014-12-01
Mobile Carriers (LTE – Quectel EM06-A):
  • PTCRB
  • AT&T
GMA (Global Market Access – Non-Radio):
  • RCM (Australia)
  • PSE, VCCI (Japan)
  • BSMI(Taiwan)
  • UKCA
  • KC (S. Korea)
  • BIS (India)

* Optional NVMe SSD card occupies 1x radio card slot
* 10G PON/SFP+ available only on 4 and 8-core SKU’s

Cordoba Edge Gateway CPE

Compact Intel® Atom® C3000-Based Universal CPE for SD-WAN and SD-Branch Applications

P/N

RMN

RTN

Cooling

Options

80500-0214-G02-SL00A
8-core Base Model
IA3003 IA3003.02 Fan
  • Intel® Atom® C3758, 8-core @ 2.2 GHz w/QAT
  • 16 GB memory with ECC
  • 128 GB NVMe SSD
  • WAN:
    • 2x 1 Gbps auto media
    • 2x 10 Gbps SFP+ cages (can also be PON)
  • LAN:
    • 4x 2.5 Gbps RJ-45
  • Preloaded Ubuntu Linux
80500-0214-G02-SL01A
8-core LTE / Wi-Fi 6
IA3003 IA3003.02A Fan
  • Intel® Atom® C3758, 8-core @ 2.2 GHz w/QAT
  • 16 GB memory with ECC
  • 128 GB NVMe SSD
  • WAN:
    • 2x 1 Gbps auto media
    • 2x 10 Gbps SFP+ cages (can also be PON)
  • WWAN: 1x 4G LTE Cat12 radio
  • LAN: 4x 2.5 Gbps RJ-45
  • WLAN: 1x Wi-Fi 6 AP radio (DB/DC)
  • Preloaded Ubuntu Linux
80500-0214-G03-SL00A
4-core Base Model
IA3003 IA3003.03 Fanless
  • Intel® Atom® C3558, 4-core @ 2.2 GHz w/QAT
  • 8 GB memory with ECC
  • 64 GB eMMC SSD
  • WAN:
    • 2x 1 Gbps auto media
    • 2x 10 Gbps SFP+ cages (can also be PON)
  • LAN: 4x 2.5 Gbps RJ-45
  • Preloaded Ubuntu Linux
80500-0214-G03-SL01A
4-core LTE / Wi-Fi 6
IA3003 IA3003.03A Fan
  • Intel® Atom® C3558, 4-core @ 2.2 GHz w/QAT
  • 8 GB memory with ECC
  • 64 GB eMMC SSD
  • WAN:
    • 2x 1 Gbps auto media
    • 2x 10 Gbps SFP+ cages (can also be PON)
  • WWAN: 1x 4G LTE Cat12 radio
  • LAN: 4x 2.5 Gbps RJ-45
  • WLAN: 1x Wi-Fi 6 AP radio (DB/DC)
  • Preloaded Ubuntu Linux
80500-0214-G05-SL00A
2-core Base Model

IA3003

IA3003.05 Fanless
  • Rackmount Intel® Atom® C3338R, 2-core @ 1.8 GHz w/QAT
  • 4 GB memory with ECC
  • 32 GB eMMC SSD
  • WAN: 2x 1 Gbps auto media
  • LAN: 4x 2.5 Gbps RJ-45
  • Preloaded Ubuntu Linuxkit
80500-0223-G00




  • Rackmount accessory kit
32800-0014-G01




  • Wall-mount accessory kit
