PE2G2B18

Dual Port Copper Gigabit Ethernet PCI Express Server Adapter Broadcom® BCM5718 Based

Silicom’s Dual Port Copper Gigabit Ethernet PCI Express Server adapter is PCI Express x4 lane, Gen-1 Copper Gigabit Ethernet network interface card that contains two Gigabit copper ports on a PCI Express adapter.

The Silicom’s Dual Port Copper Gigabit Ethernet PCI Express Server adapter is based on BCM5718 designed for Servers and high-end appliances. The performance is optimized so that system I/O is not the bottleneck in high-performance networking applications.

Silicom’s Dual Port Copper Gigabit Ethernet PCI Express Server adapter has an integrated hardware acceleration that performs TCP/UDP/IP checksum offload and TCP segmentation. The host processing offloads accelerators frees CPU for application processing.

Silicom’s Dual Port Copper Gigabit Ethernet PCI Express Server adapter is the ideal solution for implementing multiple network segments, mission-critical high-powered networking applications and environments within high performance servers.

PE2G2B18

Dual Port Copper Gigabit Ethernet PCI Express Server Adapter Broadcom® BCM5718 Based

Key Features:

  • X2 at 2.5 GT/s
  • MSI and MSI-Capabilities – up to 17 MS-X vectors
  • I/O Virtualization support for VMWare ® NetQueue ® and Microsoft ® VMQ
  • 17 receive queues and 16 transmit queues
  • Receive Side Scaling (RSS) with per queue MSI-X vector support.
  • Transmit Side scaling ( TSS) and multi-Tx queue with per queue MSI-X vector support
  • Jumbo frame support 9.6 KB
  • Virtual LAN – 802.1q VLAN tagging

Copper Gigabit Ethernet 1000Base-T :

  • Independently copper Gigabit Ethernet channels support four Gigabit Ethernet (1000Base-T), Fast Ethernet (100Base-Tx) and Ethernet (10Base-T).
  • Triple speed 1000Mbps (1000Base-T), 100 Mbps (100Base-Tx) and 10 Mbps (100Base-T) operation.
  • Nway auto negotiation automatic sensing and switching between 1Gbps full duplex and 100 / 10 Mbps operations Simplex or Full Duplex.
  • RJ-45 female connectors

PE2G2B18

Dual Port Copper Gigabit Ethernet PCI Express Server Adapter Broadcom® BCM5718 Based

Copper Gigabit Ethernet Technical Specifications – (1000Base-T) Adapters:

IEEE Standard / Network topology: Gigabit Ethernet, 1000Base-T
Fast Ethernet, 100Base-TX
Ethernet, 10Base-T
Full duplex / Simplex: Support both Simplex & Full duplex operation in all operating speeds
Auto negotiation: Auto-negotiation between Full duplex and simplex operations and between 10Mb/s 100Mb/s speeds and duplex 1000Mb/s
Data Transfer Rate: 1000 Mb/s, 100 Mb/s and 10 Mb/s in simplex mode per port
2000Mb/s 200 and 20 Mb/s in full duplex mode per port

Operating Systems Support

Operating system support: Windows
Linux

General Technical Specifications

Interface Standard: PCI-Express Base Specification Revision 2.0 ( 2.5 GTs)
Board Size: Low profile short add-in card: 127 mm X 68.91mm (5.0”X 2.713”)
PCI Express Card Type: X2 Lane , Gen-1, Mechanical format X4
PCI Express Voltage: +12V +- 8%
PCI Connector: Gold Finger: X4
Controller:  Broadcom BCM5718
Product IDs VID: 0x14e4,
PID: 0x1656,
Sub-VID:0x14e4,
Sub-PID:0x1656
I/O: Dual RJ45 located on edge of the board
Weight: 80 gram (2.822 oz)
Power Consumption: 2.52W, 0.21A at 12V:
Typical all ports operate at 1000Mb/s.
1.92W,0.16A at 12V:
Typical all ports operate at 100Mb/s.
1.80W. 0.15A at 12V:
Typical all ports operate at 10Mb/s.
1.44W, 0.12A at 12V:
Typical No link at all ports
Power Consumption (Max): 2.87W: all ports operate at 1000Mb/s.
Holder: Metal Bracket: Full Height/Low profile Height
Operating Humidity: 0%–90%, non-condensing
Operating Temperature: 0°C – 45°C (32°F – 113°F)
Storage: -20°C–65°C (-4°F–149°F)
EMC Certifications: FCC Part 15, Subpart B Class A
Conducted Emissions
Radiated Emissions
CE EN 55022: 1998 Class A Amendments A1: 2000; A2: 2003
Conducted Emissions
Radiated Emissions
CE EN 55024: 1998 Amendments A1: 2000; A2: 2003
Immunity for ITE Amendment A1: 2001
CE EN 61000-3-2 2000, Class A
Harmonic Current Emissions
CE EN 61000 3-3 1995, Amendment A1: 2001
Voltage Fluctuations and Flicker
CE IEC 6100-4-2: 1995
ESD Air Discharge 8kV. Contact Discharge 4kV.
CE IEC 6100-4-3:1995
Radiated Immunity (80-1000Mhz), 3V/m 80% A.M. by 1kHz
CE IEC 6100-4-4:1995
EFT/B: Immunity to electrical fast transients 1kV Power
Leads, 0.5Kv Signals Leads
CE IEC 6100-4-5:1995
Immunity to conductive surges COM Mode; 2kV,
Dif. Mode 1kV
CE IEC 6100-4-6:1996
Conducted immunity (0.15-80 MHz) 3VRMS 80% A.M.
By 1kHz
CE IEC 6100-4-11:1994
Voltage Dips and Short Interruptions
V reduc >95%, 30% >95% Duration 0.5per, 25per, 250per
MTBF: 237 (Years)
*According to Telcordia SR-332 Issue 1
Environmental condition – GB (Ground, Fixed, Controlled). Ambient temperature – 25°C. Temperature rise of 15°C above the system ambient temperature was assumed for the cards components

LEDs

LEDs: (3) LEDs per port
Link / Act: Turn on any Link (1000, 100 or 10), Blinks on Activity (green)
100: Turns on 100Mb/s Link (green)
1000: Turns on 1000 Mb/s Link (green)
LEDs location: LEDs are located on the PCB, visible via holes in the metal bracket holder
Connectors: (2) Shielded RJ-45

PE2G2B18

Dual Port Copper Gigabit Ethernet PCI Express Server Adapter Broadcom® BCM5718 Based

P/N

Description

Notes

PE2G2B18-R Dual Port Copper Gigabit Ethernet PCI Express Server Adapter X2 lane Gen-1 , Based on Broadcom BCM5718 /B0, Low-Profile, RoHS compliant, Mechanical format X4



Model P/N -LP / -RoHS
-R: RoHS Compliant / Lead free adapter.
-LP: Assemble Low Profile Metal Bracket, available in dual or single port only
